負荷供給系統保護リレーシステムの現状とその動向

負荷供給系統保護リレーシステムの現状とその動向

通常価格 ¥4,620 JPY
通常価格 セール価格 ¥4,620 JPY
セール 売り切れ
税込

カテゴリ: 技術報告

論文No: 1006

グループ名: 【B】電力・エネルギー部門

発行日: 2005/03/01

タイトル(英語): Present State and Trends of Load Supply System Protection Relay Systems

著者名: 負荷供給系統保護リレーシステムの現状とその動向調査専門委員会

著者名(英語): Investigating R&D Committee on Present State and Trends of Load Supply System Protection Relay System

キーワード: power systems, load supply systems, protection relays, efficiency, power system operation

要約(日本語): わが国の電力系統は需要の増大とともに ,大電源の集中化や偏在化が進み,電力の輸送は大容量,併架,多端子など大規模かつ複雑となってきている。一方,電力自由化の進展などに伴い,更なる業務の効率化や既設設備の一層の有効活用が求められ,系統の運用は制約が厳しくなることが予想される。 特に負荷供給系統保護リレーは,併架による零相循環電流の影響や小サイズ電線の溶断など,接地形態を含めた系統構成による諸現象を考慮しなければならず,従来から各電力会社は所管する系統の特徴を踏まえた最適な保護機能の実現に対して努力を行ってきている。 これらの実態を把握して将来の設備形成の効率化や系統の安定運用に寄与することを目的として,電気学会保護リレ-システム技術委員会では「負荷供給系統保護リレーシステムの現状とその動向調査専門委員会」を設置し,2002年8月から2004年7月までの2年間、負荷供給系統を主体に各電力会社の「系統構成及び事故実績」「保護リレーシステムの構成や適用の実態」を調査した。さらに,「諸現象と対策」に加え,「保護リレーシステムの特徴と課題」や「海外における実態」「今後の動向」も調査した。 本報告書は,負荷供給系統特有の諸現象への対応やそれらを踏まえた効率的な設備構成など,技術者の技術資源とすることができる。

要約(英語): For power systems in Japan the increase in demand for power, large-scale power sources have increasingly been concentrated and distributed unevenly. Electric power transmission has become larger in scale and more complicated with bulk power transmission, multi-circuit, multi-terminal and others. On the other hand, with the progress in the liberalization of the electric power industry, business activities need to be further improved in efficiency and the existing equipment needs to be utilized more effectively. Thus, constraints on power system operation are expected to be severer. In particular, for load supply system protection relays, all phenomena that may occur in various system configurations including types of grounding, such as influence of zero-phase circulating current due to multi-circuit, and melting of small-diameter conductors, must be taken into consideration. For years electric power companies have made efforts to realize the optimum protection function based on the characteristics of the power systems they each own.For the purpose of contributing to more efficient establishment of equipment and more stable operation of power systems in the future with the understanding of these facts, the Technical Committee on Power Protective Relay of the Institute of Electrical Engineers of Japan set up “Investigating R&D Committee on Present State and Trends of Load Supply System Protection Relay System”. The committee made surveys on “system configurations and fault experiences” and “protection relay system configurations and actual applications” mainly for the load supply systems of the electric power companies for 2 years, from August 2002 to July 2004. Moreover, surveys on “various phenomena and measures to handle them”, “characteristics and issues of protection relay systems”, “actual state in foreign countries” and “future trends” were also conducted.This report which presents measures to handle various phenomena specific to load supply systems, efficient equipment configurations based on the measures and other related information can serve as a technical resource for engineers.

PDFファイルサイズ: 23,433 Kバイト
