変圧器使用材料とその適用技術に関する最新動向
変圧器使用材料とその適用技術に関する最新動向
カテゴリ: 技術報告
論文No: 1271
グループ名: 【B】電力・エネルギー部門
発行日: 2012/12/20
タイトル(英語): Recent Trend of Material for Transformers and its Application Technologies
著者名: 変圧器使用材料とその適用技術に関する最新動向調査専門委員会
著者名(英語): Investigating R&D Committee of Transformer
キーワード: 電磁鋼板,アモルファス合金,連続転位電線,エステル油,超電導線材/Electrical Steel, Amorphous Alloy, Continuously Transposed Conductor, Ester Oil, Super Conducting Wire
要約(日本語): 変圧器は,100年以上の歴史を有する成熟した機器であるが,今日においてもなお,経済性・省エネ性・コンパクト性・輸送容易性・環境適合性など,様々な観点から改良・進歩が求められている。変圧器の進歩には,解析技術の高度化・構造改良とならんで,材料革新が不可欠である。しかるに,これまで「変圧器材料」という切り口でその動向を整理した文献がなかったので,最新動向を調査し本報告書にまとめた。 磁性材料においては,電磁鋼板・アモルファス合金の両者において,世界をリードしながら絶え間なく損失低減の改良が加えられている。導電材料においては,連続転位電線・自己融着電線など,電線の構成の進歩が,変圧器の製造・構造の合理化に寄与している。液体絶縁材料においては,環境適合性・難燃性の観点から,様々なエステル油やシリコーン油が開発され,適用が始まっている。変圧器固体絶縁材料の代表である絶縁紙や絶縁ボードにおいては,耐熱性の向上や誘電率の制御が行われている。モールド変圧器のエポキシ樹脂にも進歩が見られる。超電導線材の進歩に伴って超電導変圧器の開発も進んでいる。 今後も,材料の革新が,変圧器の進歩をもたらすものと期待される。
要約(英語): Transformers are the matured electro-magnetic machines that have long histories over 100years and have been improved step by step. And still, they are required for further improvement and advance from various points of view such as cost saving, energy saving, compactness, transportability and ecology etc. Material innovation is essential for the advance of transformers to meet the above needs, together with sophistication of analytical technique and improvement of construction. From the above background, and absence of papers in which the point of “transformer material” is summarized, the recent trend of the transformer materials have been researched and summarized in this report. For example, in the magnetic materials, Japanese electrical steel and amorphous alloy makers are leading the world, and making efforts to reduce the iron loss ceaselessly. In the conducting material, continuously transposed conductors and self bonded wires are popularized, and they are contributing to the reduction of eddy current loss. In the liquid insulation, several ester oil and silicone oil are developed and applied to the transformers from the view points of ecology and less-flammability. In the solid insulation, heat resistance papers and permittivity-controlled boards are applied. In addition, according to the advance of super conducting wires, development of super conducting transformers are on the way. Today and future, it is expected that material innovation will further bring the advancement of transformers.
PDFファイルサイズ: 15,354 Kバイト
