プリント基板におけるスリット構造の不要放射特性

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2012/06/01

タイトル(英語): Characteristics of Radiated Emission from a Printed Circuit Board with a Slit

著者名: 中山　健一（茨城大学大学院理工学研究科），鹿子嶋　憲一（茨城大学大学院理工学研究科），武田　茂樹（茨城大学大学院理工学研究科）

著者名(英語): Kenichi Nakayama (Graduate School of Science and Engineering, Ibaraki University), Kenichi Kagoshima (Graduate School of Science and Engineering, Ibaraki University), Shigeki Takeda (Graduate School of Science and Engineering, Ibaraki University)

キーワード: 電源・グラウンド層，平行平板共振器，共振周波数，不要電磁放射，FDTD　　power・ground plane，parallel resonator，resonant frequency，radiated emission，FDTD

要約(英語): This paper describes the mechanism of radiated emission from a PCB (printed circuit board) with a slit. The multilayer PCB has a power plane and a ground plane, and they make up a parallel resonator. It is reported that when there is a slit at the power plane, the resonant frequencies are varied and the strength of radiated emission is also altered. However, the radiated emission from the PCB with a slit has not been cleared, although it is generally thought that the amount of the radiated emission will be increased. In this paper, the radiated emission from a PCB with a slit is measured and numerically analyzed using FDTD. It has been shown that the amount of radiated emission decrease at 1st mode when there is a slit. And its reason has been also cleared by investigating both amplitude and phase of the tangential electric field on the PCB with a slit.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.132 No.6 （2012） 特集：超電導材料の合成と特性評価

本誌掲載ページ: 404-410 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/132/6/132_404/_article/-char/ja/
