流線を用いた可視化による三相誘導電動機モデル鉄心のベクトル磁気特性評価

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2023/06/01

タイトル(英語): Evaluation of Vector Magnetic Property in a Three-Phase Induction Motor Model Core with Visualization of Streamline

著者名: 甲斐　祐一郎（鹿児島大学），前田　怜哉（鹿児島大学），榎園　正人（ベクトル磁気特性技術研究所）

著者名(英語): Yuichiro Kai (Kagoshima University), Ryoya Maeda (Kagoshima University), Masato Enokizono (Vector Magnetic Characteristic Technical Laboratory)

キーワード: ベクトル磁気特性，磁気損失，三相誘導電動機モデル鉄心，流線，空間的位相差　　vector magnetic property，magnetic energy，three-phase induction motor model core，streamline，spatial phase difference

要約(英語): In this paper, a streamline display method for magnetic flux density and magnetic field strength vectors in a three-phase induction motor model core is presented, and the relationship between streamlines and magnetic properties is investigated. It is possible to visualize the vector magnetic properties distribution by representing the magnetic flux density and the magnetic field strength vector with the streamlines. In addition, the time variation of the streamlines of the magnetic flux density and magnetic field strength vectors, and magnetic energy was compared. It was clear that the magnetic energy did not necessarily increase in the areas where the magnetic flux density and magnetic field strength increased because these vectors have the spatial phase difference.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.143 No.6 （2023） 特集：最近の電力用磁性材料とその活用技術

本誌掲載ページ: 222-228 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/143/6/143_222/_article/-char/ja/
