デジタルアイソレータ用薄膜単層空心マイクロトランスの寸法依存性に関する考察

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2024/06/01

タイトル(英語): Considerations on Dimensional Dependence of Thin-Film Single-Layer Coreless Micro-Transformers for Digital Isolators

著者名: 菅原　聡（福山大学工学部），市川　智也（福山大学工学部）

著者名(英語): Satoshi Sugahara (Faculty of Engineering, Fukuyama University), Tomoya Ichikawa (Faculty of Engineering, Fukuyama University)

キーワード: 空心，デジタルアイソレータ，寸法依存性，ゲートドライバ，オンチップ，薄膜トランス　　coreless，digital isolator，dimensional dependence，gate driver，on-chip，thin-film transformers

要約(英語): Novel power semiconductor devices with high withstand voltage and high-speed operation use digital isolators for isolated transmission of gate drive signals. The isolators are required to have the similar level of withstand voltage and operating speed as the power semiconductor devices. In this work, thin-film single-layer coreless micro-transformers fabricated on silicon chips are proposed for digital isolators in power switches operating at high voltage and high speed. This paper describes the dimensional dependence of the micro-transformers. Guidelines for dimensional optimization are discussed based on theoretical analysis of the relationship between transmission characteristics and the occupied area, the number of turns, and the conductor width for the micro-transformers.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.144 No.6 （2024） 特集：磁性材料の高周波特性活用技術動向と展望

本誌掲載ページ: 207-213 p

原稿種別: 論文／日本語
