配電用変圧器のタップ動作を考慮したPV進相運転による電圧上昇抑制効果

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/05/01

タイトル(英語): A Study on Voltage Rise Control Effect by Leading Power Factor Operation of PVs Considering Tap Change of Distribution Transformer

著者名: 石丸　雅章（北陸電力（株）技術開発研究所），田町　英樹（北陸電力（株）技術開発研究所），駒見　慎太郎（北陸電力（株）技術開発研究所）

著者名(英語): Masa-aki Ishimaru (Engineering Research & Development Center, Hokuriku Electric Power Company), Hideki Tamachi (Engineering Research & Development Center, Hokuriku Electric Power Company), Shintaroh Komami (Engineering Research & Development Center, Hokuriku Electric Power Company)

キーワード: 太陽光発電，進相運転，電圧上昇，配電線縮約モデル　　photovoltaic，leading power factor operation，voltage rise，aggregated model of the distribution networks

要約(英語): Voltage rise problem in distribution networks has been discussed as the foremost concern against the penetration of large amount of photovoltaics (PVs). As a solution of such problem, using voltage regulation facility such as SVC (Static Var Compensator) or Loop power flow controller are proposed. However, it might require major investments in the distribution network and that means the cost would be imposed on the nation.In this paper, the authors focus on latent ability of the present distribution network and PVs to find solution against the problem and propose a low cost solution to mitigate the voltage rise by using constant leading power factor operation of PVs. The distribution voltages are calculated in case of increasing highly penetrated PVs, where it is very important to make an aggregated model of the distribution networks including loads and PVs. The authors aggregate a lot of loads and PVs by using an aggregation method called “Y-connection”. As a result of having simulated with the aggregated realistic model of distribution networks, the authors confirmed that using a combination of leading power factor operation by Q = -0.2P and LDC of distribution transformer make it possible to maintain adequate voltage without voltage regulation facility such as SVC.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.5 （2011）

本誌掲載ページ: 429-436 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/5/131_5_429/_article/-char/ja/
