高圧配電用避雷器の接地抵抗値が直撃雷保護効果に与える影響

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/05/01

タイトル(英語): Influence of Grounding Resistance Connecting to Surge Arresters on Effectiveness of Lightning Protection Caused by Direct Hit for Power Distribution Lines

著者名: 高橋　明久（（財）電力中央研究所　電力技術研究所），日高　哲也（中国電力（株）），石本　和之（（財）電力中央研究所　電力技術研究所），浅川　聡（（財）電力中央研究所　電力技術研究所）

著者名(英語): Akihisa Takahashi (Central Research Institute of Electric Power Industry), Tetsuya Hidaka (The Chugoku Electric Power Co., Inc.), Kazuyuki Ishimoto (Central Research Institute of Electric Power Industry), Akira Asakawa (Central Research Institute of Electric Power Industry)

キーワード: 雷，雷防護，避雷器，架空地線，配電線，接地抵抗　　lightning，lightning protection，surge arrester，overhead ground wire，distribution line，grounding resistance

要約(英語): The grounding resistance of surge arresters (Arrs) for the lightning protection of power distribution lines is generally maintained below 30Ω in Japan. Therefore, electric power companies have been spending a large amount of money on the construction and maintenance of low grounding resistances. In this paper, the influence of grounding resistance on lightning protection measures is clarified for power distribution lines with both a ground wire (GW) and Arrs by EMTP analysis and experiments. These results showed that even if the grounding resistance of Arrs becomes high, effectiveness of lightning protection is hardly decreased. Moreover, the results indicated that it is more important for constructing a rational lightning protection system to install a lot of lightning devices on power distribution lines than to lower the grounding resistance of Arrs.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.5 （2011）

本誌掲載ページ: 472-480 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/5/131_5_472/_article/-char/ja/
