電気二重層キャパシタの等価回路モデルとその応用

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/06/01

タイトル(英語): Equivalent Circuit Model for Electric Double Layer Capacitors and its Applications

著者名: 山城　迪（北見工業大学名誉教授），仲村　宏一（北見工業大学）

著者名(英語): Susumu Yamashiro (Professor Emeritus, Kitami Institute of Technology), Koichi Nakamura (Kitami Institute of Technology)

キーワード: 電気二重層キャパシタ（EDLC），等価回路モデル，実効容量，充放電効率　　electric double layer capacitor，equivalent circuit model，effective capacity，energy efficiency

要約(英語): For a better understanding and detailed analysis of electric behavior of EDLC, we present one dynamic and two static equivalent circuit models each of which consists of a resistance and a capacitance varying with voltage. The differential capacity based dynamic model is used to simulate the discharge curve. Also the integral and effective capacity based static models are applied to estimate the energy efficiency and the constant current charge-discharge time. Owing to the energy oriented approach, the effective capacity based model shows its excellence in estimating efficiency and capacitance over the integral capacity based model.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.6 （2011）

本誌掲載ページ: 524-529 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/6/131_6_524/_article/-char/ja/
