雷サージ解析のための通信線など共架線のモデリング

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/07/01

タイトル(英語): Modeling of Telecommunication Lines for Lightning Overvoltage Studies

著者名: 石本　和之（(財) 電力中央研究所電力技術研究所），野田　琢（(財) 電力中央研究所電力技術研究所），中村　真敏（中部電力（株）），丸　俊介（中部電力（株））

著者名(英語): Kazuyuki Ishimoto (Electric Power Engineering Research Lab., CRIEPI), Taku Noda (Electric Power Engineering Research Lab., CRIEPI), Masatoshi Nakamura (Chubu Electric Power Co., Inc.), Shunsuke Maru (Chubu Electric Power Co., Inc.)

キーワード: 配電線，通信線，雷，サージ解析，XTAP　　distribution line，telecommunication line，lightning，surge analysis，XTAP

要約(英語): With the progress of the information-oriented society, telecommunication lines are often installed on concrete poles along with power distribution lines. When a lightning stroke hits a distribution pole, the lightning current flows also through the telecommunication line in addition to the concrete pole and the ground wire. And, it is easily estimated that the existence of the telecommunication line reduces the currents through the concrete pole and the ground wire, and thus, reduces the voltage across the insulators to support the phase wires. However, its quantitative study has not yet been carried out.Considering the above, we have measured the surge impedance matrix of an actual-scale test distribution line equipped with a telecommunication line. Using this result, a method to model the distribution line system with the telecommunication line for lightning overvoltage simulations is proposed in this paper. Simulation results obtained by the proposed modeling method are compared with field-test results, and good agreement is obtained.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.7 （2011）

本誌掲載ページ: 591-601 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/7/131_7_591/_article/-char/ja/
