モールド絶縁における微小空気ギャップの絶縁特性

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/07/01

タイトル(英語): Insulation Behavior of Small-air-gap for the Molded-insulation System

著者名: 東山　雅一（東芝産業機器製造（株）），鈴木　勇人（東芝産業機器製造（株）），広瀬　達也（(株) 東芝），中村　勇介（(株) 東芝），前田　照彦（(株) 東芝），葉山　貴志（三重大学），中村　修平（三重大学），梅村　時博（三重大学），小迫　雅裕（九州工業大学），匹田　政幸（九州工業大学）

著者名(英語): Masakazu Higashiyama (Toshiba Industrial Products Manufacturing Co.), Hayato Suzuki (Toshiba Industrial Products Manufacturing Co.), Tatsuya Hirose (Toshiba Co.), Yusuke Nakamura (Toshiba Co.), Teruhiko Maeda (Toshiba Co.), Takashi Hayama (Mie University), Shuhei Nakamura (Mie University), Hiro Umemura (Mie University), Masahio Kozako (Kyushu Institute of Technology), Masayuki Hikita (Kyushu Institute of Technology)

キーワード: 微小ギャップ，モールド変圧器，部分放電，初期電子，Paschenの法則，エポキシ樹脂　　small-air-gap，cast-resin transformer，partial discharge，initiating electron，Paschen's law，epoxy-resin

要約(英語): Insulation behavior of small-air-gap for the molded insulation system has been investigated by comparing the well-known Paschen curve. Three electrode systems Metal-Gap-Metal (MGM), Metal-Gap-Insulator (MGI) and Insulator-Gap-Insulator (IGI) were employed as the test samples. It was found that Vs (breakdown voltage of the air gap) of the MGM were higher than the conventional Paschen curve, which can be attributed to the lacked initiating electron for Vs. This behavior was also obtained for MGI and IGI system. However, X-ray irradiation gives the remarkable effect on these Vs resulting in the coincidence to the Paschen data. According to the references' data-review and some experimental data for Paschen minimum region, new fundamental and universal Paschen curve for the solid insulation system was proposed.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.7 （2011）

本誌掲載ページ: 630-636 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/7/131_7_630/_article/-char/ja/
