エポキシ絶縁用部分放電検出装置の開発

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/08/01

タイトル(英語): Development of Partial Discharge Sensing Device for Epoxy Resin Bushing

著者名: 牟田神東　達也（(株) かんでんエンジニアリング 変電工事部），川崎　誠（(株) かんでんエンジニアリング 変電工事部），羽柴　靖人（関西電力（株）電力技術研究所）

著者名(英語): Tatsuya Mutakamihigashi (Power Transformation Construction work Department, Kaden Engineering Co., Inc.), Makoto Kawasaki (Power Transformation Construction work Department, Kanden Engineering Co., Inc.), Yasuhito Hashiba (Power Engineering R&D Center, Kansai Electric Power Co., Inc.)

キーワード: 部分放電，電磁波，検出装置，エポキシ樹脂ブッシング　　partial discharge，electro-magnetic wave，sensing device，epoxy bushing

要約(英語): For the electric power equipment and the cables, prevention of accident is very important. And in substations, a lot of solid insulations using epoxy resin are introduced into cubicle-type switchgears because of its high insulation reliability and down-sizing ability. We know a phenomenon that partial discharge occur when electric installation have degraded. When void or crack exist in the polymer insulating materials or interface of conductor, partial discharge is caused and finally results in breakdown. In recent years, the feature is seen in the partial discharge generated in the epoxy resin before and after the progress of electric tree by our research. Electro-magnetic wave spectra radiated from partial discharge have specific frequency region from 200MHz to 450MHz. We developed the sensing device that can detect the electric discharge by receiving the signal by mobile antenna. We proved the performance of this equipment in operating substations; As a result, partial discharge in epoxy resin was detected by electro-magnetic wave. And then, we removed epoxy resin bushing from the cubicle and measured partial discharge by discharging current, we confirmed that presumed level is correct.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.8 （2011）

本誌掲載ページ: 687-692 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/8/131_8_687/_article/-char/ja/
