防護管内CVTケーブルにおけるアーク短絡故障時の圧力上昇・伝搬特性モデルの提案

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/08/01

タイトル(英語): Proposal on Modeling of Pressure-rise and Propagation due to Short-circuit Fault Arc on a CVT Cable Installed in a Protective Pipe

著者名: 田所　兼（(財) 電力中央研究所 電力技術研究所），大高　聡也（(財) 電力中央研究所 電力技術研究所），天川　正士（(財) 電力中央研究所 電力技術研究所）

著者名(英語): Tomo Tadokoro (Electric Power Engineering Research Lab., Central Research Institute of Electric Power Industry), Toshiya Ohtaka (Electric Power Engineering Research Lab., Central Research Institute of Electric Power Industry), Tadashi Amakawa (Electric Power Engineering Research Lab., Central Research Institute of Electric Power Industry)

キーワード: 地中配電，アーク，数値流体力学，圧力上昇，CVTケーブル　　underground distribution，arc，computational fluid dynamics，pressure-rise，CVT cable

要約(英語): In underground distribution systems, a CVT (Cross-Linked Polyethylene Insulated PVC Sheathed Triplex) cable is installed in a protective pipe. When a fault arc occurs on the CVT cable, instantly the pressure increases due to the high temperature of the arc and it propagates in the pipe. The pressure-rise and propagation may seriously damage to the pipe and connected power equipment. There are many different sizes of pipes and cables depending on the installation situations, and fault arc occurs under various conditions. Therefore, the simulation technique is effective for examining such pressure-rise and propagation in addition to short-circuit tests. The objective of this paper is to present a CFD (Computational Fluid Dynamics) modeling that can be used to evaluate the characteristics of the pressure-rise and propagation by the fault arc in the protective pipe. As a result, the pressure-rise waveforms by the CFD analysis were similar to those short-circuit test results. In addition, the dependences of maximum pressure-rise on the sizes of the CVT cable and arc current were simulated well. Therefore, the CFD modeling is sufficient for the study of the pressure-rise and propagation in the protective pipe.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.8 （2011）

本誌掲載ページ: 693-700 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/8/131_8_693/_article/-char/ja/
