同期発電機の制動巻線による分散形電源連系時の三相不平衡の改善

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/09/01

タイトル(英語): Improvement of Three-phase Unbalance due to Connection of Dispersed Generator by Damper Windings of Synchronous Generator

著者名: 松木　純也（福井大学大学院工学研究科電気・電子工学専攻），田岡　久雄（福井大学大学院工学研究科電気・電子工学専攻），林　泰弘（早稲田大学大学院先進理工学研究科電気・情報生命工学専攻），岩本　繁（福井大学大学院工学研究科電気・電子工学専攻），大穀　晃裕（三菱電機 (株)）

著者名(英語): Junya Matsuki (Graduate School of Electrical and Electronics Engineering, University of Fukui), Hisao Taoka (Graduate School of Electrical and Electronics Engineering, University of Fukui), Yasuhiro Hayashi (School of Advanced Science and Engineering, Dept. of Electrical Eng. and Bioscience, Waseda University), Shigeru Iwamoto (Graduate School of Electrical and Electronics Engineering, University of Fukui), Akihiro Daikoku (Mitsubishi Electric Corporation)

キーワード: 制動巻線，三相不平衡，分散形電源，制動巻線電流，電機子電流　　damper windings，three-phase unbalance，dispersed generator，damper current，armature current

要約(英語): It is well known in the numerical simulation of synchronous generator that the damper winding contributes to suppress the three-phase circuit unbalance in power systems. However, experimental study has not been performed yet. In this paper, authors verify experimentally the suppression of the three-phase unbalance by the damper windings. In order to simulate the three-phase unbalance, a 470W dispersed generator of single-phase-two-line type is connected to a three-phase laboratory-scale power system that includes a 6kVA synchronous generator. Authors measured and analyzed line voltages and currents as well as damper bar currents both with and without dispersed generator. The influence of damper windings to the unbalance of three-phase circuit is also investigated. The results show that the damper winding contributes to improve the three-phase unbalance.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.9 （2011）

本誌掲載ページ: 724-729 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/9/131_9_724/_article/-char/ja/
