配電系統における高次高調波共振の抑制法

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/09/01

タイトル(英語): A Suppression Method of Higher Harmonics Resonance in Distribution System

著者名: 杉村　翔士（室蘭工業大学），内藤　督（室蘭工業大学），遠山　篤（室蘭工業大学），太田　文彦（東京電力（株）技術開発研究所）

著者名(英語): Shouji Sugimura (Muroran Institute of Technology), Tadashi Naitoh (Muroran Institute of Technology), Atsushi Toyama (Muroran Institute of Technology), Fumihiko Ohta (Engineering R&D Division, Tokyo Electric Power Company)

キーワード: 高次高調波共振，配電系統，固有モード，影響度，抑制法，直交条件　　higher harmonics resonance，distribution system，eigen mode，participation factor，suppression method，orthogonal condition

要約(英語): There are many PWM control apparatuses, which are higher harmonics current sources, in distribution systems. And higher harmonics causes over current by parallel resonance. To avoid the over current, it is necessary to suppress the resonance.In this paper, a new suppression method, which uses the effect of source connected point in resonance circuit, is proposed. Firstly it shows that the optimal point, which gives a minimum current amplification degree, is orthogonal to static condenser voltage. And then, using eigenvector of state equation, the participation factor is defined. When the participation factor is zero, the orthogonal condition is introduced. Therefore the optimal point is given by using with the participation factor. Finally, adopting numerical examination, it is known that multiple optimal points usually exist. Therefore, we can choose the advantageous point as a source connected node.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.9 （2011）

本誌掲載ページ: 737-746 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/9/131_9_737/_article/-char/ja/
