雷による低圧電子式電力量計の故障要因とその対策 ―電磁障害防止方法に関する実験的検討―

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/09/01

タイトル(英語): The Mechanisms and Countermeasures of Failure in Low-Voltage Electronic Watt-Hour-Meters Caused by Lightning --A Study on Effective Method to Prevent Electromagnetic Disturbance--

著者名: 浅川　聡（(財) 電力中央研究所），古河　征二（九州電力 (株)），高橋　明久（中国電力 (株)），石本　和之（(財) 電力中央研究所）

著者名(英語): Akira Asakawa (Central Research Institute of Electric Power Industry), Seiji Hurukawa (Kyushu Electric Power Co., Inc.), Akihisa Takahashi (The Chugoku Electric Power Co., Inc.), Kazuyuki Ishimoto (Central Research Institute of Electric Power Industry)

キーワード: 雷，配電線，電子式電力量計，耐雷設計　　lightning，distribution line，electronic watt-hour-meter，lightning protection design

要約(英語): Experimental study was carried out for classified a mechanism of failure of low-voltage electronic Watt-Hour Meters. As the results, the mechanism of failure of electronic meters is clarified into two patterns. One is due to the magnetic field generated by lightning current passing through the inside of an electronic meter. The other is due to the blow out of electric wire caused by lightning current flowing into the power supply circuit for processing unit. For these failure mechanisms, following counter measures were clarified. One is that a magnetic shielding measure using a metallic plate covering the processing unit was effective for reducing the magnetic field. The other measure is that a relocation of the ZnO device in the electronic meter was effective for reducing the lightning current flowing into the power supply circuit.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.9 （2011）

本誌掲載ページ: 793-800 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/9/131_9_793/_article/-char/ja/
