Investigation of Lightning Rod Shielding Angle

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/10/01

タイトル(英語): Investigation of Lightning Rod Shielding Angle

著者名: Mohamed Nayel (Electrical and Electronics Engineering Depatment, Xian Jiaotong Liverpool University)

著者名(英語): Mohamed Nayel (Electrical and Electronics Engineering Depatment, Xian Jiaotong Liverpool University)

キーワード: lightning rod，lightning leader，attractive radius，charge simulation method，electromagnetic

要約(英語): This paper studies those parameters affecting the shielding angle of the lightning rod (Franklin Rod) above very tall buildings. It was recommended that the shielding angle of the lightning rod is about 45～60°. The downward lightning leader is modeled by using discrete line charges to consider the exponential distribution of charges through the downward leader. The voltage condition used by Rizk is used to investigate the inception of the upward lightning leader. Different air conditions (relative air density and air humidity) are considered for more practical simulation. The influences of lightning parameters and lightning rod height on the shielding angle are studied. The results shows that, lightning leader parameters, lightning rod height and ground slope have series effects on the lightning rod shielding angle. Based on the results, a lightning rod shielding angle for shielding design is recommended to decrease the lightning stroke to the lightning rod.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.10 （2011）

本誌掲載ページ: 855-858 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/10/131_10_855/_article/-char/ja/
