無効電力補償装置用交流フィルタの新設計手法と実系統試験結果との比較検討

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2011/11/01

タイトル(英語): An Actual Design of AC Filter for Static Var Compensator and Verification Results from the Field Test

著者名: 田村　裕治（(株) 東芝），高崎　真司（九州電力（株）大分支店），色川　彰一（(株) 東芝），武田　秀雄（(株) 東芝），高木　喜久雄（(株) 東芝），野呂　康宏（(株) 東芝），雨谷　昭弘（同志社大学）

著者名(英語): Yuji Tamura (Toshiba Corporation), Shinji Takasaki (Oita Branch Office, Kyusyu Electric Power Co., Inc.), Shoichi Irokawa (Toshiba Corporation), Hideo Takeda (Toshiba Corporation), Kikuo Takagi (Toshiba Corporation), Yasuhiro Noro (Toshiba Corporation), Akihiro Ametani (Doshisha University)

キーワード: 交流フィルタ，無効電力補償装置，直流送電，高調波解析　　AC filter，static var compensator，HVDC，harmonic analysis

要約(英語): AC filter design method for SVC and HVDC is commonly known in the relevant CIGRE technical brochure and IEC technical report. However the conventional method requires many iterative calculations of the harmonic voltages and currents until the calculation results become within the regulation levels by changing filter parameters based on the experience. In this respect, a new improved design method is proposed, which enables efficient evaluation on the complex impedance plane to confirm as to whether the proposed filter impedance is in the permissible range. In an actual project of Okuura SVC of Kyusyu Electric Power Co., Inc., the new method was applied to the AC filter design. This paper describes on the actual procedure of the AC filter design with the new method, the actual references of the harmonic performance calculation, and the field test measurement results on Okuura SVC. The calculation results and the filed measurement results are consistent with each other, thus the validity of the new design method is verified on its accuracy and effectiveness.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.131 No.11 （2011）

本誌掲載ページ: 876-884 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/131/11/131_11_876/_article/-char/ja/
