配電系励磁突入電流による電圧低下率の簡易計算ツールの開発
配電系励磁突入電流による電圧低下率の簡易計算ツールの開発
カテゴリ: 論文誌(論文単位)
グループ名: 【B】電力・エネルギー部門
発行日: 2012/02/01
タイトル(英語): Development of a Simplified Calculation Tool for Voltage Drop caused by Transformer Inrush in Distribution System
著者名: 中地 芳紀(中部電力(株)技術開発本部),深江 隆之(中部電力(株)),菅原 敏則(中部電力(株)),中村 逸人(中部電力(株)),小山 満明(中部電力(株)),上田 玄(中部電力(株)技術開発本部)
著者名(英語): Yoshiki Nakachi (R&D Division, Chubu Electric Power Co., Inc.), Takayuki Fukae (Chubu Electric Power Co., Inc.), Toshinori Sugahara (Chubu Electric Power Co., Inc.), Hayato Nakamura (Chubu Electric Power Co., Inc.), Mitsuaki Koyama (Chubu Electric Power Co., Inc.), Fukashi Ueda (R&D Division, Chubu Electric Power Co., Inc.)
キーワード: 変圧器飽和,励磁突入電流,電圧低下,配電系統 transformer saturation,inrush current,voltage drop,distribution system
要約(英語): It is well known that the voltage drop due to the inrush current at energizing transformer, may at times, interrupt electrical equipment. Generally, the voltage drop is calculated by using the sophisticated tool such as EMTP, so the transformer saturation phenomenon has been properly represented. However, it is not practical for distribution system engineers to calculate the voltage drop with transformer inrush by using EMTP, because there are a lot of network access requests needing such calculations with many kinds of transformers. Therefore, in this paper, a simplified and easy-to-use calculation tool for voltage drop caused by transformer inrush in distribution system is developed. In order to grasp the voltage drop by inrush current during the planning stage, it is formulated by considering the transformer saturation/unsaturation periods in each winding type, the developed tool is based on the versatile spreadsheet software such as Microsoft Excel(R) It can be used with accuracy almost similar to the EMTP.
本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.132 No.2 (2012) 特集:IWHV 2010
本誌掲載ページ: 197-206 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/132/2/132_2_197/_article/-char/ja/
