自立型光CTの開発

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2012/05/01

タイトル(英語): Development of Independent-type Optical CT

著者名: 山口　達史（東光電気（株）商品開発研究所），塩澤　大五郎（東光電気（株）商品開発研究所），六戸　敏昭（(株) 日立製作所 日立研究所），木田　順三（(株) 日本AEパワーシステムズ 開閉装置事業部），張　偉（(株) 日本AEパワーシステムズ 開閉装置事業部）

著者名(英語): Tatsushi Yamaguchi (R & D Laboratory, Toko Electric Corporation), Daigoro Shiozawa (R & D Laboratory, Toko Electric Corporation), Toshiaki Rokunohe (Hitachi Research Laboratory, Hitachi, Ltd.), Junzo Kida (High Voltage Switchgear Business Division, Japan AE Power Systems Corporation), Wei Zhang (High Voltage Switchgear Business Division, Japan AE Power Systems Corporation)

キーワード: ファラデー効果，光変流器，光ファイバ電流センサ，絶縁破壊，温度特性　　faraday effect，optical current transformer，optical fiber current sensor，dielectric breakdown，temperature characteristics

要約(英語): Optical current transformers (optical CTs) have features that they can be made much smaller and lighter than conventional electromagnetic induction transformers by their simple structure, and contribute to improvement of equipment reliability because of their excellent surge resistance performance. Authors consider optical CTs to be next generation transformers, and are conducting research and development of optical CTs aiming to apply to measuring and protection in electric power systems. Specifically we developed an independent-type optical CT by utilizing basic data of optical CTs accumulated for large current characteristics, temperature characteristics, vibration resistance characteristics, and so on. In performance verification, type tests complying with IEC standards, such as short-time current tests, insulation tests, accuracy tests, and so on, showed good results.This report describes basic principle and configuration of optical CTs. After that, as basic characteristics of optical CTs, conditions and results of verification tests for dielectric breakdown characteristics of sensor fibers, large current characteristics, temperature characteristics, and vibration resistance characteristics are described. Finally, development outline of the independent-type optical CT aiming to apply to all digital substation and its type tests results are described.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.132 No.5 （2012） 特集：電力・エネルギー分野を支える変電技術の新展開

本誌掲載ページ: 415-421 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/132/5/132_5_415/_article/-char/ja/
