低圧系統用自動電圧調整機器の開発

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2012/05/01

タイトル(英語): Development of Automatic Voltage Regulator for Low Voltage Distribution Systems

著者名: 松田　勝弘（東北電力（株）研究開発センター），堀越　和宏（東北電力（株）お客さま本部配電部），瀬戸　寿之（東北電力（株）お客さま本部配電部），井山　治（サンケン電気（株）技術本部PS事業部），小林　広武（(財) 電力中央研究所システム技術研究所）

著者名(英語): Katsuhiro Matsuda (Research & Development Center, Tohoku Electric Power Co., Inc.), Kazuhiro Horikoshi (Distribution Engineering Dept., Customer Services Div., Tohoku Electric Power Co., Inc.), Toshiyuki Seto (Distribution Engineering Dept., Customer Services Div., Tohoku Electric Power Co., Inc.), Osamu Iyama (Power System Division, Engineering Headquarters, Sanken Electric Co., Ltd.), Hiromu Kobayashi (System Engineering Research Laboratory, Central Research Institute of Electric Power Industry)

キーワード: 配電系統，太陽光発電，集中連系，発電出力抑制，電圧調整　　distribution system，photovoltaic power generation，clustered installation，suppression of generated output，voltage control

要約(英語): This paper presents the development of a new type of voltage regulator that can adequately maintain the voltage supplied to customers, dealing with the problem of voltage control along with the widespread use of photovoltaic power generation systems. The developed equipment is a pole-mounted type voltage regulator consisting of a step-down transformer that converts voltage from high to low and a series transformer for voltage compensation.The demonstration test conducted at the CRIEPI Akagi Test Center confirmed that the voltage control function of the developed voltage regulator is satisfactory based on the proposed control algorism. Also, simulation analysis, on the assumption of the clustered installation of photovoltaic power generation systems, confirmed that the introduction of the developed voltage regulator enables the system voltage to be adequately maintained and full photovoltaic power generation is possible without suppressing the output. It is anticipated that the developed voltage regulator is very effective in adequately regulating the voltage for low voltage distribution systems and gives an effective way for even more widespread photovoltaic power generation.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.132 No.5 （2012） 特集：電力・エネルギー分野を支える変電技術の新展開

本誌掲載ページ: 436-444 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/132/5/132_5_436/_article/-char/ja/
