広域多地点で観測されたアンサンブル平均日射変動の標準偏差と最大変動幅との関係

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2012/05/01

タイトル(英語): Relationship between Standard Deviation and Maximum Fluctuation Width of Ensemble Average Insolation Observed at Multi-points in Large Area

著者名: 加藤　丈佳（名古屋大学大学院工学研究科電子情報システム専攻），井上　貴人（名古屋大学大学院工学研究科電子情報システム専攻），本田　信行（中部電力（株）技術開発本部電力技術研究所），小相澤　政和（中部電力（株）技術開発本部電力技術研究所），西野　慎一（中部電力（株）技術開発本部電力技術研究所），鈴置　保雄（名古屋大学大学院工学研究科電子情報システム専攻）

著者名(英語): Takeyoshi Kato (Dept. of Electrical Eng. and Comp. Sci., Grad. School of Eng., Nagoya University), Takato Inoue (Dept. of Electrical Eng. and Comp. Sci., Grad. School of Eng., Nagoya University), Nobuyuki Honda (Electric Power Research & Development Center, Chubu Electric Power Co., Inc.), Kazumasa Koaizawa (Electric Power Research & Development Center, Chubu Electric Power Co., Inc.), Shinichi Nishino (Electric Power Research & Development Center, Chubu Electric Power Co., Inc.), Yasuo Suzuoki (Dept. of Electrical Eng. and Comp. Sci., Grad. School of Eng., Nagoya University)

キーワード: 太陽光発電，日射変動，平滑化効果，標準偏差，最大変動幅　　photovoltaic power generation，insolation fluctuation，smoothing effect，standard deviation，maximum fluctuation width

要約(英語): For the detailed impact assessment of the total power output fluctuation of high penetration photovoltaic power generation system in terms of the load-frequency control, this study evaluated the relationship between the standard deviation (STD) including only shorter cycles than 32 minute and the maximum fluctuation width (MFW) calculated with various window width by using the two data-sets of multi-points observed insolation data. The main results are as follows. The R2 of regression line of STD - MFW correlation diagram is larger than 0.85 for various seasons, while the slope of regression line slightly varies with seasons. The slope of regression line is almost the same for various area sizes during the same season, although the variation ranges of both STD and MFW reduce with larger window width due to a so-called smoothing effect. The results suggest that if the STD of geographical average insolation can be calculated by using stochastic method, the MFW can be calculated with a linear function of STD because of the good correlation between STD and MFW independently of seasons and area sizes.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.132 No.5 （2012） 特集：電力・エネルギー分野を支える変電技術の新展開

本誌掲載ページ: 445-451 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/132/5/132_5_445/_article/-char/ja/
