深埋設絶縁独立接地とメッシュ接地の過渡特性に関する実験的検討

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2012/05/01

タイトル(英語): Experimental Studies about Transient Characteristics of a Deeply Buried Grounding Electrode and a Grounding Mesh

著者名: 山本　和男（中部大学電気システム工学科），柳川　俊一（(株) 昭電），関岡　昇三（湘南工科大学）

著者名(英語): Kazuo Yamamoto (Department of Electrical Engineering, Chubu University), Shunichi Yanagawa (Shoden Co., Ltd.), Shozo Sekioka (Shonam Institute of Technology)

キーワード: 接地，雷，メッシュ接地，深埋設絶縁独立接地，電位上昇　　grounding，lightning，grounding mesh，deeply buried grounding electrode，potential rise

要約(英語): When lightning strikes the tower of a cellular phone base station or other such facilities, power and communication equipments in the vicinity of the tower may suffer extensive damages due to the lightning current flowing backward from the grounding system of the tower. The use of a deeply buried grounding electrode has been proposed recently to suppress such back flow current and a potential rise in the vicinity of the tower. The deeply buried grounding electrode is a bare conductor buried deep in the ground that is connected to a lightning rod on the ground by an insulated wire. When lightning strikes the lightning rod, the lightning current is directed to the electrode from which it diffuses to the ground. The deeply buried grounding electrodes have been installed in cellular phone base stations and other such facilities to solve such problems caused by the back flow current and the potential rise. A grounding mesh is usually laid around such base stations as a grounding system for the facilities on the ground. Therefore, it is important to understand the interactions between the deeply buried grounding electrode and the grounding mesh. In this study, experiments on the interactions between a grounding mesh and a deeply buried grounding electrode have been carried out. Additionally, the transient characteristics of the mesh grounding have researched.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.132 No.5 （2012） 特集：電力・エネルギー分野を支える変電技術の新展開

本誌掲載ページ: 500-506 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/132/5/132_5_500/_article/-char/ja/
