電気二重層キャパシタの新しい等価回路定数測定法

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2012/05/01

タイトル(英語): Innovative Measurement Methods of EDLC's Equivalent Circuit Constants

著者名: 山城　迪（北見工業大学名誉教授），仲村　宏一（北見工業大学）

著者名(英語): Susumu Yamashiro (Professor emeritus at Kitami Institute of Technology), Koichi Nakamura (Kitami Institute of Technology)

キーワード: 電気二重層キャパシタ（EDLC），内部抵抗，静電容量，EDLCの試験法　　electric double layer capacitor (EDLC)，internal resistance，capacitance，test method of EDLC

要約(英語): Two kinds of innovative measurement method of EDLC's equivalent circuit constants are presented in this paper, "simplified energy method" and "charge-energy method". The measurement principle of the former method is the same as that of the previously reported "energy method", but the procedure is much more simplified by employing an analytical approach. In addition to energy, electric charge is incorporated into the latter one to estimate an internal resistance analytically using a simultaneous equation regarding energy and charge. Through the verification with the constant current charge-discharge experiments, we confirmed that both of the proposed measurement methods are concise, highly accurate and reliable.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.132 No.5 （2012） 特集：電力・エネルギー分野を支える変電技術の新展開

本誌掲載ページ: 515-520 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/132/5/132_5_515/_article/-char/ja/
