C型CIP法の雷電磁界解析への応用
C型CIP法の雷電磁界解析への応用
カテゴリ: 論文誌(論文単位)
グループ名: 【B】電力・エネルギー部門
発行日: 2013/01/01
タイトル(英語): Application of the Type-C Constrained Interpolation Profile Method to Lightning Electromagnetic Field Analyses
著者名: 梶田 健太(同志社大学 理工学部),宮川 昂太(同志社大学 理工学部),馬場 吉弘(同志社大学 理工学部),長岡 直人(同志社大学 理工学部),雨谷 昭弘(同志社大学 理工学部),高見 潤(東京電力(株)技術開発研究所),岡部 成光(東京電力(株)技術開発研究所)
著者名(英語): Kenta Kajita (College of Science and Engineering, Doshisha University), Kohta Miyagawa (College of Science and Engineering, Doshisha University), Yoshihiro Baba (College of Science and Engineering, Doshisha University), Naoto Nagaoka (College of Science and Engineering, Doshisha University), Akihiro Ametani (College of Science and Engineering, Doshisha University), Jun Takami (R&D Center, Tokyo Electric Power Company), Shigemitsu Okabe (R&D Center, Tokyo Electric Power Company)
キーワード: CIP法,電磁界,FDTD法,雷 constrained interpolation profile method,electromagnetic field,finite-difference time-domain method,lightning
要約(英語): The type-C constrained interpolation profile (CIP) method has been applied to analyzing lightning electromagnetic fields. The CIP method is one of the finite-difference methods. Differently from the finite-difference time-domain (FDTD) method, however, it considers not only electric- and magnetic-field values at each discretized points in a working space but also their spatial-derivative values there. Therefore, in principle, it can compute fields accurately even when a relatively coarse grid and a relatively large time increment are used. In section 2 of this paper, a numerical procedure for computing electromagnetic fields in a three-dimensional space using the CIP method is presented. In section 3, the type-C CIP method is applied to computing electric fields in a uniform grid, which are generated by a lightning return-stroke current wave propagating upward along a vertical straight channel located on flat perfectly conducting ground, and the CIP-computed waveforms are compared with the corresponding waveforms computed theoretically and using the FDTD method. In section 4, the method is applied to computing lightning electric fields in a nonuniform grid, and a similar comparison is made.
本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.133 No.1 (2013) 特集:平成24 年電力・エネルギー部門大会
本誌掲載ページ: 106-113 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/1/133_106/_article/-char/ja/
