バンク事故復旧対応型LRT・SVR協調電圧制御手法

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/04/01

タイトル(英語): Cooperation Voltage Control Method of LRT and SVR in Distribution System with PV Systems Corresponding to Bank Fault Restoration

著者名: 芳澤　信哉（早稲田大学先進理工学研究科電気・情報生命専攻），林　泰弘（早稲田大学先進理工学研究科電気・情報生命専攻），辻　祐毅（東京電力（株）電力流通本部配電部配電技術グループ），神谷　英志（東京電力（株）電力流通本部配電部配電技術グループ）

著者名(英語): Shinya Yoshizawa (Graduate School of Advanced Science and Engineering, Dept. Of Electrical Eng. and Bioscience, Waseda University), Yasuhiro Hayashi (Graduate School of Advanced Science and Engineering, Dept. Of Electrical Eng. and Bioscience, Waseda University), Masaki Tsuji (Tokyo Electric Power Company), Eiji Kamiya (Tokyo Electric Power Company)

キーワード: 電圧制御，バンク事故復旧，配電系統，負荷時タップ切替変圧器，自動電圧調整器，太陽光発電　　voltage control，bank fault restoration，distribution system，LRT，SVR，PV system

要約(英語): Voltages in distribution system are maintained within a proper voltage range by adjusting a tap position of Load Ratio control Transformer (LRT) and Step Voltage Regulator (SVR). In Japan, many voltage control methods have been researched. However, these conventional methods do not presuppose the bank fault restoration. Since the main purpose of voltage control of the conventional restoration approach is to reduce the amount of voltage violation in distribution system, the number of customers with voltage violation cannot be reduced to zero during a bank fault restoration. In this paper, the authors propose a cooperation voltage control method of LRT and SVR to minimize the number of customers with voltage violation corresponding to the bank fault restoration in distribution systems with PV systems. In the proposed method, the tap position of SVR is controlled after the control of LRT to avoid frequent tap changes and each tap position of voltage control devices is controlled to minimize the number of customers with voltage violation. In order to check the effectiveness of the proposed method, the simulation using distribution system model with PV systems is performed under various conditions.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.133 No.4 （2013） 特集：スマートグリッド実現に向けた電力系統技術

本誌掲載ページ: 333-342 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/4/133_333/_article/-char/ja/
