直流事故電流を抑制可能な自励式直流送電システムの制御保護方式

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/05/01

タイトル(英語): Control and Protection Scheme of VSC HVDC Transmission System having the Ability to Control DC Fault Current

著者名: 菊間　俊明（（一財）電力中央研究所），竹中　清（（一財）電力中央研究所），高崎　昌洋（（一財）電力中央研究所），福島　知之（北海道電力（株）），内海　貴徳（北海道電力（株））

著者名(英語): Toshiaki Kikuma (Central Research Institute of Electric Power Industry), Kiyoshi Takenaka (Central Research Institute of Electric Power Industry), Masahiro Takasaki (Central Research Institute of Electric Power Industry), Tomoyuki Fukushima (Hokkaido Electric Power Co., Inc.), Takanori Uchiumi (Hokkaido Electric Power Co., Inc.)

キーワード: 直流送電，自励式変換器，事故保護，マルチレベル変換器　　HVDC transmission，voltage source converter，fault protection，multi-level converter

要約(英語): Practical application of the VSC (Voltage Source Converter) HVDC system is progressing recently due to its superior control performance over the conventional line-commutated converter type HVDC system. Introduction of the VSC HVDC will continue to spread further by the appearance of MMC (Modular Multilevel Converter) topology.At present, AC circuit breaker is tripped to clear fault when a DC fault occurs at a VSC HVDC system. Tripping AC circuit breaker delays recovery from the fault. The application of the full bridge cell MMC is considered as one of the solutions to clear the fault without tripping AC circuit breaker. However, any specific control scheme using the full bridge cell MMC has not been proposed. We propose a novel control scheme of the VSC HVDC system which can control DC fault current and recovery quickly from the fault.We verified performance of the control scheme through transient simulation. The VSC HVDC system can maintain stable operation without overcurrent and overvoltage on semiconductor devices during entire AC and DC fault period. It was confirmed that HVDC system with the control scheme can restore power transmission quickly after both AC and DC system faults.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.133 No.5 （2013） 特集：大電流現象の数値シミュレーション技術の新展開

本誌掲載ページ: 449-456 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/5/133_449/_article/-char/ja/
