分散型電源が連系された配電系統における故障点標定の精度に関する考察
分散型電源が連系された配電系統における故障点標定の精度に関する考察
カテゴリ: 論文誌(論文単位)
グループ名: 【B】電力・エネルギー部門
発行日: 2013/06/01
タイトル(英語): A Study on Accuracy of Fault Locator in Distribution System with Distributed Generations
著者名: 飯岡 大輔(名城大学 理工学部電気電子工学科),林 泰弘(早稲田大学大学院先進理工学研究科)
著者名(英語): Daisuke Iioka (Dept. of Electrical and Electronic Engineering, Faculty of Science and Technology, Meijo University), Yasuhiro Hayashi (Graduate School of Advanced Science and Engineering, Waseda University)
キーワード: 故障点標定,インバータ型分散型電源,配電系統 fault locator,inverter based distributed generation,distribution system
要約(英語): A fault locator system in a loop-shaped distribution system with inverter based distributed generations is proposed. An algorithm of proposed fault locator system is based on the impedance obtained by the phase-voltage and line-current at the transformer feeder in the power distribution substation. We have proposed the quadratic equation expressed in terms of fault location. The quadratic equation represents the impedance from the substation to the fault location. Inserting the impedance obtained by the voltage and current at the transformer feeder into the quadratic equation, two candidates of the fault location are obtained. We can select the true fault location from the two candidates by using the characteristics of impedance calculated by the voltage and current at the incoming feeder of distributed generation. The validity of the fault locator system was investigated by PSCAD/EMTDC simulations. As a result, it was found that impedance obtained by the information of the substation and distributed generations are useful for searching the fault location in the loop-shaped distribution system.
本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.133 No.6 (2013) 特集:電力インフラと電気自動車の融合
本誌掲載ページ: 515-522 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/6/133_515/_article/-char/ja/
