未復旧負荷の最小化を目指す配電系統の事故復旧論理の開発

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/07/01

タイトル(英語): Development of Process for Reconfiguring the Faulted Distribution Network for Minimizing Loads without Electric Power Supply

著者名: 神　直亨（日本大学 生産工学部 電気電子工学科），佐藤　正弘（日本大学 生産工学部 電気電子工学科）

著者名(英語): Naoyuki Jin (College of Industrial Technology, Nihon Univercity), Masahiro Sato (College of Industrial Technology, Nihon Univercity)

キーワード: 配電系統，事故復旧，系統構成，組合せ最適化　　distribution network，restoration，configuration of network，combinatorial optimization

要約(英語): When a configuration of distribution system is radial, a load of every customer is served from single distribution substation. Therefore, a fault that takes place at the distribution substation causes every load in the system out of electricity. Then, it is required to supply electricity from the neighboring distribution networks to the faulted network by modifying the on/off status of circuit breakers (CB) within the faulted network and tie-lines that can connect the faulted system and the neighboring networks. For finding a new configuration of distribution system, following constraints should be checked: a configuration of distribution system must be radial, no overload in any line occurs, every customer should be supplied electricity or the number of customers without electricity should be minimized. In order to find the most desirable configuration, many cases of combinations of the on/off status of CBs are formed as candidates that should be checked if they satisfy the aforementioned constraints. Since many numbers of CBs are implemented in actual distribution system, it may be impossible to check every candidate because it takes very long computation time. In order to shorten the computation time, this paper proposes approaches with some criteria by which procedures checking the constraints is terminated during processing for finding solutions and also the number of candidates to be checked if they satisfy the constraints is reduced. Numerical examples carried out for a system with 30CBs. The total number of candidates that will be formed by using every combination of CBs is 230 (≒ 1.0 × 109). The number of candidates that are checked by the proposed method is 6158 that is about 1/180000 of the total number of candidates. In addition, solutions obtained by the proposed method accorded with those obtained by using every combination of CBs. This shows that the number of candidates that can be checked within a limited time will be increased greatly by using the proposed method.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.133 No.7 （2013）

本誌掲載ページ: 623-630 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/7/133_623/_article/-char/ja/
