Wave Propagation Characteristics on a Pipe-Type Cable in Particular Reference to the Proximity Effect

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/12/02

タイトル(英語): Wave Propagation Characteristics on a Pipe-Type Cable in Particular Reference to the Proximity Effect

著者名: Akihiro Ametani (Department of Electrical Engineering, Doshisha University), Kazuki Kawamura (Department of Electrical Engineering, Doshisha University), Asha Shendge (Department of Electrical Engineering, Doshisha University), Naoto Nagaoka (Department o

著者名(英語): Akihiro Ametani (Department of Electrical Engineering, Doshisha University), Kazuki Kawamura (Department of Electrical Engineering, Doshisha University), Asha Shendge (Department of Electrical Engineering, Doshisha University), Naoto Nagaoka (Department of Electrical Engineering, Doshisha University), Yoshihiro Baba (Department of Electrical Engineering, Doshisha University)

キーワード: impedance，frequency response，pipe-type cable，proximity effect，EMTP，FDTD

要約(英語): This paper has investigated the frequency and time responses of wave/surge propagation characteristics on a pipe-type cable based on a theoretical analysis, EMTP and FDTD simulations, as a function of the separation distance of the inner conductor from the center of the pipe enclosure. It is found that the conductor resistance increases and the inductance decreases as the separation distance increases, i.e. the eccentricity becomes greater, due to the proximity effect. The increase of the resistance and the decrease of the inductance are more pronounced as the frequency increases. Correspondingly, the attenuation increases and the characteristic impedance decreases as the eccentricity increases. Also, a transient voltage becomes smaller and a transient current becomes higher as the eccentricity becomes greater. EMTP simulation results are confirmed to agree satisfactorily with FDTD simulation results.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.133 No.12 （2013） 特集：System Technical Performance（系統の技術性能）

本誌掲載ページ: 954-960 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/12/133_954/_article/-char/ja/
