Study on Lightning Overvoltage Generated on Power Distribution Lines with Telecommunication Cables

Study on Lightning Overvoltage Generated on Power Distribution Lines with Telecommunication Cables

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/12/02

タイトル(英語): Study on Lightning Overvoltage Generated on Power Distribution Lines with Telecommunication Cables

著者名: Kazuyuki Ishimoto (Central Research Institute of Electric Power Industry), Takao Kawazoe (Central Research Institute of Electric Power Industry), Tetsuya Hidaka (Central Research Institute of Electric Power Industry), Akira Asakawa (Central Research Insti

著者名(英語): Kazuyuki Ishimoto (Central Research Institute of Electric Power Industry), Takao Kawazoe (Central Research Institute of Electric Power Industry), Tetsuya Hidaka (Central Research Institute of Electric Power Industry), Akira Asakawa (Central Research Institute of Electric Power Industry)

キーワード: lightning protection design,distribution line,telecommunication cable,lightning overvoltage analysis

要約(英語): Due to the progress of information-oriented societies all over the world, telecommunication cables are often installed on concrete poles along with power distribution lines. When a lightning stroke hits a concrete pole equipped with an overhead ground wire and a telecommunication cable, the lightning current is split into the three paths: the concrete pole, the overhead ground wire, and the telecommunication cable. It is easily estimated that the existence of the telecommunication cable reduces the current through the concrete pole, and thus, reduces the voltages across the insulators which support the phase wires. However, its quantitative study has not yet been carried out. In this paper, we clarified the effect of the telecommunication cable on reducing the voltages across the phase-wire insulators from the both sides of an actual-scale distribution line test and EMTP (Electro-Magnetic Transients Program) analysis.

本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.133 No.12 (2013) 特集:System Technical Performance(系統の技術性能)

本誌掲載ページ: 967-973 p

原稿種別: 論文/英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/12/133_967/_article/-char/ja/
