Analysis of Lightning Current at Home Electric Appliance in Case of Stroke to Concrete Pole

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/12/02

タイトル(英語): Analysis of Lightning Current at Home Electric Appliance in Case of Stroke to Concrete Pole

著者名: Koji Michishita (Gradutae School of Engineering, Shizuoka University), Ayato Suzuki (Gradutae School of Engineering, Shizuoka University), Shigeru Yokoyama (Gradutae School of Engineering, Shizuoka University), Yasuji Hongo (R&D Center, Tohoku Electric Po

著者名(英語): Koji Michishita (Gradutae School of Engineering, Shizuoka University), Ayato Suzuki (Gradutae School of Engineering, Shizuoka University), Shigeru Yokoyama (Gradutae School of Engineering, Shizuoka University), Yasuji Hongo (R&D Center, Tohoku Electric Power Co., Inc.)

キーワード: lightning，distribution line，SPD (surge protective device)，concrete pole

要約(英語): With the advent of highly advanced information-oriented society, the appliances connected to the telecommunication line come to be widely used in the house, and it is reported that these appliances are frequently damaged by lightning. The home electric appliances have a built-in SPD (Surge Protective Device), damaged with the excess of the amount of charge passing through. In this paper, the authors estimate the lightning surge on an indoor distribution line by using the VSTL (Virtual Surge Test Lab. ) where the FDTD (Finite Difference Time Domain) method is adopted. The accuracy of the calculated results by the VSTL is verified by comparison with the experimental results. The lightning current resulting in the damage of the SPD of the home electric appliances is investigated in the case of the direct strokes to the concrete pole where not only the 6.6kV distribution line but also the low-voltage line are installed, and it turns out that the estimated damage rate reasonably agrees with the reported rate.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.133 No.12 （2013） 特集：System Technical Performance（系統の技術性能）

本誌掲載ページ: 981-986 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/12/133_981/_article/-char/ja/
