Parameters Determination for a. c. Voltage and Current Waveforms Generated by IEC 61083-4 TDG

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/12/02

タイトル(英語): Parameters Determination for a. c. Voltage and Current Waveforms Generated by IEC 61083-4 TDG

著者名: Shuji Sato (Graduate School of Engineering, Utsunomiya University), Yuya Saikawa (Graduate School of Engineering, Utsunomiya University), Seisuke Nishimura (UHV Laboratory, Nippon Institute of Technology), Hiroyuki Shimizu (UHV Laboratory, Nippon Institut

著者名(英語): Shuji Sato (Graduate School of Engineering, Utsunomiya University), Yuya Saikawa (Graduate School of Engineering, Utsunomiya University), Seisuke Nishimura (UHV Laboratory, Nippon Institute of Technology), Hiroyuki Shimizu (UHV Laboratory, Nippon Institute of Technology), Yoshifumi Okamoto (Graduate School of Engineering, Utsunomiya University), Hisatoshi Ikeda (School of Engineering, The University of Tokyo)

キーワード: steady state a.c.，short-term a.c.，IEC 61083-4 TDG，FFT，base curve，digital recorder

要約(英語): IEC 61083-4, which is to be completed in 2013, defines requirements for a software which analyses a. c. and d. c. waveform parameters distilled from digitally measured data. TDG (Test Data Generator) attached to the 61083-4 simulates digitally recorded data for typical waveforms observed in daily measurement. Any acceptable software can determine waveform parameters within a given margin specified in IEC 61083-4. Authors could successfully analyse all the a. c. waveforms generated by the TDG using techniques, 1) FFT after an interpolation for steady a. c. and 2) a base curve for short-term a. c. The latter involves the least square method and a set of non-linear equations. The distilled parameters for both waveforms are within the specified margins (0.1% in peak value) proposed in IEC 61083-4. The details of the algorithm are to be clarified in the paper. Also mentioned in the paper is a proposed TDG's controversial behaviour in which a current-zero instant is shifted due to a discrete sampling interval.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.133 No.12 （2013） 特集：System Technical Performance（系統の技術性能）

本誌掲載ページ: 1001-1008 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/12/133_1001/_article/-char/ja/
