特高需要家における高次高調波の電圧ひずみと対策
特高需要家における高次高調波の電圧ひずみと対策
カテゴリ: 論文誌(論文単位)
グループ名: 【B】電力・エネルギー部門
発行日: 2014/01/01
タイトル(英語): Voltage Distortion of High-Order Harmonic on a 22kV Customer and a Countermeasure
著者名: 岡田 有功((一財)電力中央研究所 システム技術研究所),雪平 謙二((一財)電力中央研究所 システム技術研究所),中井 茂雄(九州電力 お客さま本部 配電技術試験センター),矢野 京二(九州電力 お客さま本部 配電技術試験センター)
著者名(英語): Naotaka Okada (System Engineering Research Lab. CRIEPI), Kenji Yukihira (System Engineering Research Lab. CRIEPI), Shigeo Nakai (Kyushu Electric Power Co., Inc.), Kyouji Yano (Kyushu Electric Power Co., Inc.)
キーワード: 高次高調波,特高需要家,進相コンデンサ high-order harmonic,22kV customer,shunt capacitor
要約(英語): Voltage distortion of high-order harmonic has occurred at a 22kV customer. There are only two customers who are supplied by this 22kV distribution feeder. Therefore, it is likely that induction heater of another customer have become the harmonic source. In 22kV customer, so far, there are no cases where such voltage distortion has occurred. It is necessary to understand the actual condition for this case and to clarify the effective countermeasure.As a result of analyzing the measured data, even though the high-order harmonic current generated from the induction heater is small, the voltage distortion of the high-order harmonic was increased. This is suggests that the current generated by the induction heater and the impedance conditions of the distribution system generate voltage distortion. We have constructed an analysis model, and have considered a countermeasure utilizing shunt capacitor by simulation. Based on the results of the simulation, we have demonstrated the effect of the shunt capacitor.
本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.134 No.1 (2014) 特集:平成25年電力・エネルギー部門大会
本誌掲載ページ: 32-39 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/134/1/134_32/_article/-char/ja/
