超高圧大容量ばね操作GCBの高速化技術

超高圧大容量ばね操作GCBの高速化技術

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2014/01/01

タイトル(英語): High-speed Spring Operated Mechanism for High-voltage Large-capacity Gas Circuit Breakers

著者名: 橋本 裕明((株)日立製作所日立研究所),大久保 健一((株)日立製作所電力システム社),廣瀬 誠((株)日立製作所電力システム社)

著者名(英語): Hiroaki Hashimoto (Hitachi, Ltd., Hitachi Research Laboratory), Kenichi Ookubo (Hitachi, Ltd., Power Systems Company), Makoto Hirose (Hitachi, Ltd., Power Systems Company)

キーワード: ガス遮断器,ばね操作器,2サイクル遮断  gas circuit breaker,spring-operated mechanism,2-cycle interruption

要約(英語): High-speed spring-operated mechanism that enables 2-cycle interruption was developed by improving the trip control unit and the link mechanism that connects the interrupter. This mechanism had almost the same composition as a conventional 3-cycle interruption GCB, and we optimized the mechanism to achieve 2-cycle interruption. The solenoid was optimally designed by using a coupled analysis of a nonlinear magnetic field analysis with finite elements model and a dynamic analysis with a kinematic model. We used these analyses to investigate the core material, the number of coil turns, and the stroke of the solenoid. We also calculated the dynamic characteristics of the GCB with the spring operated mechanism in order to satisfy the objective time of opening contact, and the lever of the trip control unit and the lever of the link mechanism were improved. A prototype GCB, which was built based on the above analyses, demonstrated sufficient performance.

本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.134 No.1 (2014) 特集:平成25年電力・エネルギー部門大会

本誌掲載ページ: 49-56 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/134/1/134_49/_article/-char/ja/
