PCSに生ずる雷サージ電圧解析と過電圧低減法

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2014/02/01

タイトル(英語): A Numerical Simulation of a Lightning Overvoltage on a PCS and its Reduction Method

著者名: 久保　佑太（同志社大学），長岡　直人（同志社大学），馬場　吉弘（同志社大学），雨谷　昭弘（同志社大学）

著者名(英語): Yuta Kubo (Doshisha University), Naoto Nagaoka (Doshisha University), Yoshihiro Baba (Doshisha University), Akihiro Ametani (Doshisha University)

キーワード: 太陽光発電システム，パワーコンディショナ，雷サージ，模擬試験，直撃雷，汎用回路解析プログラムEMTP　　photovoltaic generation system，PCS，lightning surge，simulation experiment，direct lightning，EMTP

要約(英語): A reduction method of a lightning overvoltage on a Power Conditioning System (PCS) is investigated in this paper. The capacitors installed between the circuit and grounding terminal in the PCS determine the response against a first transient. The inductances, winding capacitances and excitation losses of the coils for the filter in the PCS should be also considered for estimating the overvoltage to ground at an input terminal of the PCS. The dominant factors of the maximum overvoltage are a grounding resistance, capacitances between a frame and output terminal of a solar panel and those between the PCS and ground. The overvoltage is decreased with decreasing the grounding resistance of the structure for the solar panels. The grounding resistance of the PCS has a minor effect on the overvoltage. The overvoltage can be reduced when a common grounding method is applied. A length of a cable between the output terminal of the solar panel and the input terminal of the PCS should be as short as possible.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.134 No.2 （2014） 特集：接地と雷害・EMC対策

本誌掲載ページ: 99-106 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/134/2/134_99/_article/-char/ja/
