近似式を用いた埋設地線サージ伝搬特性に関する検討

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2014/02/01

タイトル(英語): A Study of Surge Propagation Characteristics of Grounding Conductor using Approximate Formulas

著者名: 関岡　昇三（湘南工科大学）

著者名(英語): Shozo Sekioka (Shonan Institute of Technology)

キーワード: 接地抵抗，分布定数線路，埋設地線，雷サージ　　grounding resistance，distributed-parameter line，grounding conductor，lightning surge

要約(英語): The surge characteristics of a grounding conductor are quite different from those of an overhead wire. It is difficult to represent the characteristics of a grounding conductor in time domain without numerical simulation. This paper describes approximate formulas for voltage and current in a horizontal grounding conductor. The formulas are derived in time domain on the basis of the lattice diagram method, and are very simple. It is convenient from the engineer's point of view to do rough estimation of surge characteristics of a grounding conductor by the approximate formulas. Some empirical laws on the grounding have been employed without any discussions. The surge characteristics of a grounding conductor are discussed using the approximate formulas.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.134 No.2 （2014） 特集：接地と雷害・EMC対策

本誌掲載ページ: 107-113 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/134/2/134_107/_article/-char/ja/
