電源長期停止時における移相変圧器を用いた電力潮流調整計画手法

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2014/02/01

タイトル(英語): A Power Flow Adjustment Planning using Phase Shifting Transformers for Long Term Generation Outages

著者名: 小河原　竜一（早稲田大学　電気・情報生命工学科），川浦　裕貴（早稲田大学　電気・情報生命工学科），岩本　伸一（早稲田大学　電気・情報生命工学科），上川　直大（東京電力（株）電力流通本部），難波　雅之（東京電力（株）電力流通本部）

著者名(英語): Ryuichi Ogahara (Dept. of Electrical Eng. & Bioscience, Waseda University), Yuki Kawaura (Dept. of Electrical Eng. & Bioscience, Waseda University), Shinichi Iwamoto (Dept. of Electrical Eng. & Bioscience, Waseda University), Naohiro Kamikawa (Tokyo Electric Power Company), Masayuki Namba (Tokyo Electric Power Company)

キーワード: 電力系統，流通設備計画，移相変圧器，線路潮流感度，分枝限定法　　power system，transmission planning，phase shifting transformer，line flow sensitivity，branch and bound method

要約(英語): High growth in electricity demand during the period of Japan's bubble economy resulted in the construction of many power transmission facilities, including some loop systems. In some loop systems, there is a possibility of considerable power flow differences between heavy and light loads. Significant changes in the power system, such as from damage due to a natural disaster, would likely result in even larger differences and ineffective use of the loop system. Phase shifting transformers (PSTs) are highly efficient equipment for solving such power flow problems and some studies of operation methods using active power flow sensitivity have been carried out. Calculating active power flow sensitivity, however, requires using the DC method. Since doing so requires the fulfillment of several assumptions, errors may appear in the calculation results. This paper assumes protracted significant local loss of generation capability (about 20% of total capacity), and examines the resulting load changes in the loop system. We then propose use of PSTs to alleviate load differences among transmission lines, allowing more effective use of the loop system. Specifically, we propose the concept of active power flow sensitivity (APFS) and active power flow sensitivity 2 (APFS2). Installing PSTs at optimal locations and operating the PSTs with proper phase angles determined by a branch and bound method, we mitigate loading differences between heavily and lightly loaded transmission lines. The validity of the proposed method is confirmed by using a modified IEEJ EAST 30 model.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.134 No.2 （2014） 特集：接地と雷害・EMC対策

本誌掲載ページ: 145-152 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/134/2/134_145/_article/-char/ja/
