電力系統の第5次高調波電圧に対する負荷グループ別の影響評価

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2016/01/01

タイトル(英語): Evaluation of Contribution by Each Different Group of Load to the Fifth Harmonic Voltage in the Electric Power System

著者名: 雪平　謙二（（一財）電力中央研究所　システム技術研究所），岡田　有功（（一財）電力中央研究所　システム技術研究所），渡辺　雅人（東京電力（株）技術開発センター）

著者名(英語): Kenji Yukihira (Central Reseaerch Institute of Electric Power Industry), Naotaka Okada (Central Reseaerch Institute of Electric Power Industry), Masato Watanabe (R&D Center, Tokyo Electric Power Company)

キーワード: 高調波，需要家，影響，定量分析，位相角　　harmonics，consumer，contribution，quantitative analysis，phase angle

要約(英語): Although the number of pieces of equipment that emit harmonic currents has increased, the harmonic voltages in Japan have gradually decreased since about 1999. In addition, the harmonic voltages are generally lower during the daytime when there is greater usage of different types of equipment that emit harmonic currents. In a previous study, the authors showed that the reason for this phenomenon is that the phase angles of the harmonic currents emitted by three-phase equipment of consumers using 6.6kV or higher voltage power supply and the phase angles of harmonic currents emitted by other equipment are almost opposite, and they cancel each other out.In this paper, we classify equipment into six groups depending on the number of phases (i.e., single-phase or three-phase) and users' supply voltage. And the ratio of the contribution of each group to the fifth harmonic voltage is then quantitatively clarified. Time trends of the fifth harmonic current per kW and the effective power of each group are assumed by using measured data. The ratio of each group is assumed by making the time trends of the composite fifth harmonic current of all groups and the average of the fifth harmonic voltage as identical as possible. By comparing them with actual sales data from an electric power company, we confirmed the feasibility of the assumed ratios.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.136 No.1 （2016） 特集：平成27年電力・エネルギー部門大会

本誌掲載ページ: 2023/02/10 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/136/1/136_2/_article/-char/ja/
