家庭用ヒートポンプ給湯機の可制御負荷利用時における需要側・系統側影響の検討

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2016/01/01

タイトル(英語): Fundamental Study on Demand and Grid Side Impact by Use of a Heat Pump Water Heater for Household as a Controllable Load

著者名: 奥谷　和也（東京大学大学院新領域創成科学研究科），馬場　旬平（東京大学大学院新領域創成科学研究科），太田　豊（東京都市大学工学部電気電子工学科）

著者名(英語): Kazuya Okutani (Graduate School of Frontier Sciences, The University of Tokyo), Jumpei Baba (Graduate School of Frontier Sciences, The University of Tokyo), Yutaka Ota (Department of Electrical and Electronic Engineering, Tokyo City University)

キーワード: スマートグリッド，可制御負荷，ヒートポンプ給湯機　　smart grid，controllable load，heat pump water heater

要約(英語): Heat pump water heater (HPWH) for household has been focused as a controllable load to compensate power fluctuation of renewable energy (RE) sources like photo voltaic (PV) cells, wind turbine (WT) and so on. HPWH should be operated without loss of user's convenience during power compensation. In this paper, HPWH model has been mode by use of a commercial HPWH with small change. The HPWH used in the study can be control the rotation speed of compressor by external signals, and it almost operates under the normal conditions as the HPWH without any change. Simulation studies have been done to evaluate loss of hot water demand by use of measured 60 hot water demands with power compensation control, and to evaluate the LFC capacity of the model gird with battery energy storage system. From simulation results, it is shown that The LFC capacity of the grid becomes large according to the capacity of HPWH, and loss of hot water demand under power control is relatively small and if several start-up/shutdown operation is allowed, the loss of hot water may be negligible small. The required energy for the hot water demand is almost the same value as mid-night operation.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.136 No.1 （2016） 特集：平成27年電力・エネルギー部門大会

本誌掲載ページ: 72-78 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/136/1/136_72/_article/-char/ja/
