配電用避雷器の1相省略による雷保護効果の検討

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2016/01/01

タイトル(英語): A Study of Lightning Protection Effect of Distribution Lines with Non-Surge Arresters on One Phase

著者名: 松浦　進（北陸電力（株）技術開発研究所），森松　達（北陸電力（株）技術開発研究所），浅岡　由伸（北陸電力（株）富山支店），石本　和之（（一財）電力中央研究所電力技術研究所）

著者名(英語): Susumu Matsuura (Engineering Research & Development Center, Hokuriku Electric Power Company), Satoshi Morimatsu (Engineering Research & Development Center, Hokuriku Electric Power Company), Yoshinobu Asaoka (Toyama Branch, Hokuriku Electric Power Company), Kazuyuki Ishimoto (Electric Power Engineering Research Laboratory, Central Research Institute of Electric Power Industry)

キーワード: 配電線，雷，雷保護効果，スパークオーバ，避雷器　　distribution line，lightning，lightning protection effect，sparkover，surge arrester

要約(英語): In Hokuriku Electric Power Company, surge arresters or distribution equipments, such as insulators with MO varistors and current-limiting arcing horns with a MO varistor, are installed on all high-voltage distribution poles in the area where a large number of lightning outages occurred. General distribution systems in Japan are isolated neutral systems, and if sparkover of insulators occurs only at one phase due to lightning-related overvoltages, a follow current will naturally disappear because of a small ground-fault current. Therefore, if the surge arresters are installed on only two phases, it is possible to prevent short circuits which cause phase-wire breakings. In the case of the two-phase arresters, sparkover of one phase without an arrester may reduce currents flowing through arresters of other phases, and may prevent failures of other phase arresters. However, this lightning protection effect has not yet been studied sufficiently. In this paper, we present that the lightning protection effect of distribution lines with non-surge arresters on one phase were obtained by experiments and EMTP simulations.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.136 No.1 （2016） 特集：平成27年電力・エネルギー部門大会

本誌掲載ページ: 106-113 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/136/1/136_106/_article/-char/ja/
