真空バルブ内真空度低下時における放電検知手法の検討

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2016/02/01

タイトル(英語): The Electric Discharge Detection Method in the Low Vacuum Region of Vacuum Interrupter

著者名: 安部　淳一（三菱電機（株）先端技術総合研究所），田辺　智子（三菱電機（株）先端技術総合研究所），矢野　知孝（三菱電機（株）先端技術総合研究所），吉田　暁（三菱電機（株）受配電システム製作所），井上　直明（三菱電機（株）受配電システム製作所）

著者名(英語): Junichi Abe (Advanced Technology R&D Center, Mitsubishi Electric Cop.), Tomoko Tanabe (Advanced Technology R&D Center, Mitsubishi Electric Cop.), Tomotaka Yano (Advanced Technology R&D Center, Mitsubishi Electric Cop.), Satoru Yoshida (Power Distribution Systems Center, Mitsubishi Electric Cop.), Naoaki Inoue (Power Distribution Systems Center, Mitsubishi Electric Cop.)

キーワード: 真空遮断器，真空バルブ，真空放電，真空絶縁，CBM，アンテナ　　vacuum circuit breaker，vacuum switch tube，vacuum discharge，vacuum-insulation，condition based maintenance，antenna

要約(英語): The Vacuum Circuit Breaker (VCB) achieves the high current interrupting capability in the pressure lower than 10-5Pa. When gas pressure increases, the breakdown voltage of a VCB decreases according to Paschen's law, and in the case of small leak, the partial discharge will occur in the VCB and the high frequency electromagnetic waves are radiated. So, we have developed the partial discharge detection system using an antenna with the region from 200MHz to 300MHz placed inside the VCB. However, if the partial discharge occurs outside the VCB, the detection system leads to misdetection as the partial discharge inside the VCB. In order to improve the performance of partial discharge detection, the outputs of antenna voltages inside and outside the VCB are investigated.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.136 No.2 （2016）

本誌掲載ページ: 154-160 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/136/2/136_154/_article/-char/ja/
