固有過渡回復電圧測定時の電流零点

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2016/02/01

タイトル(英語): Current Zero at Prospective Transient Recovery Voltage Measurement

著者名: 腰塚　正（東京電機大学工学部電気電子工学科），谷口　安彦（東京電機大学工学部電気電子工学科），萩森　英一（東京大学先端電力エネルギー・環境技術教育研究センター），池田　久利（東京大学先端電力エネルギー・環境技術教育研究センター），宇田川　恵佑（（株）東芝）

著者名(英語): Tadashi Koshizuka (Faculty of Engineering, Department of Electrical and Electronic Engineering, Tokyo Denki University), Yasuhiko Taniguchi (Faculty of Engineering, Department of Electrical and Electronic Engineering, Tokyo Denki University), Eiichi Haginomori (APET, The University of Tokyo), Hisatoshi Ikeda (APET, The University of Tokyo), Keisuke Udagawa (Toshiba Co.)

キーワード: 過渡回復電圧，端子短絡故障，電流零点，ダイオード，SiCダイオード　　transient recovery voltage，breaker terminal fault，current zero，diode，SiC diode

要約(英語): The prospective transient recovery voltage (TRV) at current interruption for circuit breakers should be measured by using ideal circuit breaker. But, it is very difficult to measure the prospective TRV because there is no ideal circuit breaker. It is often used a vacuum circuit breaker or a diode to measure the TRV. It is difficult to decide the current zero by the arc voltage or the forward voltage drop. This paper shows the new method to decide the current zero for breaker terminal fault (BTF) interrupting condition at low voltage measurements using diode. It was found that the SiC diode is suitable to use the TRV measurement. The forward voltage drop of the SiC diode is nearly constant. The terminal voltage of the diode in BTF circuit during the current flowing is nearly constant regardless of the interrupting current. But, the terminal voltage after current interruption is varied with the amplitude of the current. The current zero is a border between the voltage constant region and varied region. We can find the current zero from the voltage waveforms by plural measurements.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.136 No.2 （2016）

本誌掲載ページ: 170-174 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/136/2/136_170/_article/-char/ja/
