垂直同軸ケーブルのサージ特性に関する検討

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2016/02/01

タイトル(英語): Investigation of Surge Characteristics of Vertically Arranged Co-axial Cable

著者名: 大城　諒士（琉球大学大学院理工学研究科生産エネルギー工学専攻），我那覇　和奎（琉球大学理工学研究科電気電子工学専攻），原田　繁実（琉球大学工学部電気電子工学科），金子　英治（琉球大学工学部電気電子工学科）

著者名(英語): Ryoji Oshiro (Doctral Program, Material, Structural and Energy Engineering Course, Universiry of the Ryukyus), Kazuki Ganaha (Master's Program, Electrical and Electronics Engineering Course, University of the Ryukyus), Shigemi Harada (Electrical and Electronics Engineering, Faculty of Engineering, University of the Ryukyus), Eiji Kaneko (Electrical and Electronics Engineering, Faculty of Engineering, University of the Ryukyus)

キーワード: サージインピーダンス，垂直同軸ケーブル，EMTP，VSTL rev.　　surge impedance，vertical co-axial cable，EMTP，VSTL rev.

要約(英語): In EMTP, it is very hard to simulate a vertically arranged cable, since its surge impedance gradually changes with the distance from the ground to a top point. In the past, some researches about surge impedances and responses of vertical conductor (for example transmission tower, concrete pole and so on.) have been carried out, these researches are being continued now. However, there is no model of vertical co-axial cable in EMTP. In order to analyze surge voltage arisen on the electrical system, approach of method for treating this model in EMTP is required. In this paper, experiments of surge impedance and response on vertical cable, method of treating for vertical co-axial cable in EMTP and accuracy confirmed as compared result of this model with analysis result of VSTL Rev. (Virtual Surge Test Lab. rev. ) which is constructed under FDTD (Finite Difference Time Domain) method, are reported.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.136 No.2 （2016）

本誌掲載ページ: 184-191 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/136/2/136_184/_article/-char/ja/
