電磁操作方式真空遮断器の機構CBM機能の開発

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2016/02/01

タイトル(英語): Development of Mechanical CBM System for Electromagnetically Actuated Vacuum Circuit Breaker

著者名: 矢野　知孝（三菱電機（株）先端技術総合研究所電機システム技術部），松永　敏宏（三菱電機（株）受配電システム製作所受配電システム部），有岡　正博（三菱電機（株）受配電システム製作所受配電システム部），小山　健一（三菱電機（株）情報技術総合研究所），竹内　敏惠（三菱電機（株）福山製作所遮断器製造部）

著者名(英語): Tomotaka Yano (Advanced Technology R&D Center, Mitsubishi Electric Corporation), Toshihiro Matsunaga (Power Distribution Systems Center, Mitsubishi Electric Corporation), Masahiro Arioka (Power Distribution Systems Center, Mitsubishi Electric Corporation), Kenichi Koyama (Information Technology R&D Center, Mitsubishi Electric Corporation), Toshie Takeuchi (Fukuyama Works, Mitsubishi Electric Corporation)

キーワード: 真空遮断器，CBM，電磁アクチュエータ　　vacuum circuit breaker，condition based maintenance，electromagnetic actuator

要約(英語): A new mechanical CBM (Condition Based Maintenance) system for an electromagnetically actuated vacuum circuit breaker (VCB) has been developed. This CBM function has a new monitoring method using analysis of the coil current profile of the actuator operation. The VCB has three sets of vacuum interrupters, insulating rods, contact pressure springs and electromagnetic actuators. The electromagnetic actuators control each phase independently. We have clarified the variation in the actuator's current profile by the developed analytical method when the value of friction, contact erosion and driving capacitance changes. We have established a diagnostic method for the mechanical condition using this current profile analysis. With this method, a new remote monitoring system of the mechanical condition using current monitors on the actuator's controller has been developed and mounted on VCB for cubicle type gas insulated switchgears rating from 7.2kV to 84kV. The maintenance for mechanical parts of VCB changes to the CBM system from the conventional TBM (Time Based Maintenance) system using this monitoring system. The developed mechanical CBM system significantly reduces the life cycle cost including the labor cost of maintenance.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.136 No.2 （2016）

本誌掲載ページ: 192-197 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/136/2/136_192/_article/-char/ja/
