太陽光発電FRT要件における出力復帰特性が電力系統の過渡安定度に与える影響解析

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2016/03/01

タイトル(英語): Impact of Post-Fault Active Power Recovery of Photovoltaic Power Generation on Transient Stability

著者名: 河辺　賢一（富山大学大学院理工学研究部先進電力システム寄附講座），松田　一成（富山大学大学院理工学教育部先進電力システム寄附講座），田中　和幸（富山大学大学院理工学研究部先進電力システム寄附講座）

著者名(英語): Kenichi Kawabe (Graduate School of Science and Engineering for Research, University of Toyama), Issei Matsuda (Graduate School of Science and Engineering for Education, University of Toyama), Kazuyuki Tanaka (Graduate School of Science and Engineering for Research, University of Toyama)

キーワード: 電力系統，過渡安定度，太陽光発電，FRT機能，誘導電動機　　power system，transient stability，photovoltaic power generation，fault ride-through capability，induction motor

要約(英語): Currently, Japanese grid codes require photovoltaic (PV) power generation systems to continue supplying power to the grid as soon as possible even if the systems temporarily stop their operation. Although the fault ride-through (FRT) capability was originally proposed for preventing a cascading frequency drop in the power system, the capability has the impact on other instability phenomena such as transient stability. In this study, we focus on the post-fault active power recovery of the PV systems. The impact of the recovery speed on the transient stability is investigated under different load conditions, static/dynamic load condition. Numerical examples are carried out for the one-machine one-load infinite-bus system, and the effects of the recovery speed are evaluated by equal area criterion and critical clearing time. As a result, we have found both desirable and undesirable effects on the transient stability depending on the load condition.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.136 No.3 （2016）

本誌掲載ページ: 236-244 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/136/3/136_236/_article/-char/ja/
