PV導入量拡大を目的としたLRTおよびSVRと蓄電池による協調電圧制御手法

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2016/03/01

タイトル(英語): Cooperating Voltage Control Method between Battery Energy Storage System and LRT and SVR for Purpose of Expansion of PV Introduction

著者名: 吉永　淳（早稲田大学先進理工学研究科電気・情報生命専攻／（独）科学技術振興機構,CREST），赤木　覚（早稲田大学先進理工学研究科先進理工学専攻／（独）科学技術振興機構,CREST），伊藤　雅一（早稲田大学先進理工学研究科電気・情報生命専攻／（独）科学技術振興機構,CREST），林　泰弘（早稲田大学先進理工学研究科電気・情報生命専攻／（独）科学技術振興機構,CREST），石橋　一成（東京電力（株）パワーグリッド・カンパニー 配電部　配電制御G）

著者名(英語): Jun Yoshinaga (Dept of Electrical Engineering and Bioscience, Graduate School of Advanced Science and Engineering, Waseda University/Japan Science and Technology Agency CREST), Satoru Akagi (Dept of Advanced Science and Engineering, Graduate School of Advanced Science and Engineering, Waseda University/Japan Science and Technology Agency CREST), Masakazu Ito (Dept of Electrical Engineering and Bioscience, Graduate School of Advanced Science and Engineering, Waseda University/Japan Science and Technology Agency CREST), Yasuhiro Hayashi (Dept of Electrical Engineering and Bioscience, Graduate School of Advanced Science and Engineering, Waseda University/Japan Science and Technology Agency CREST), Kazunari Ishibashi (Distribution Engineering Group, Distribution Department, Power Grid Company, Tokyo Electric Power Company)

キーワード: 蓄電池，PV，無効電力制御，LRT，SVR，協調制御　　battery energy storage system (BESS)，photovoltaic (PV)，reactive power control，LRT，SVR，cooperating control

要約(英語): Voltage deviation in distribution networks and photovoltaic (PV) output restriction, caused by a large amount of PV systems installation, have been issued recently. BESS (Battery Energy Storage System) is one of the solutions. However, the detailed evaluation of the voltage control effect of BESS has not been carried out, because its effect varies according to BESS placement, its output and configuration of distribution, etc. Therefore, the amount of PV introduction limits in several distribution networks were evaluated and effective BESS arrangement and output control were examined in this paper. The effectiveness of the proposed BESS cooperating voltage control method with LRT, SVR was verified using numerical simulation and experiment of distribution system simulator.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.136 No.3 （2016）

本誌掲載ページ: 291-301 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/136/3/136_291/_article/-char/ja/
