複数の電圧上昇対策を考慮した無効電力補償装置の費用対効果分析手法

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2017/01/01

タイトル(英語): Cost-effectiveness Analysis of Reactive Power Compensator under Multiple Voltage Stabilization Measures

著者名: 高木　雅昭（電力中央研究所 社会経済研究所），田頭　直人（電力中央研究所 社会経済研究所），岡田　健司（電力中央研究所 社会経済研究所），浅野　浩志（電力中央研究所 社会経済研究所）

著者名(英語): Masaaki Takagi (Socio-economic Research Center, Central Research Institute of Electric Power Industry), Naoto Tagashira (Socio-economic Research Center, Central Research Institute of Electric Power Industry), Kenji Okada (Socio-economic Research Center, Central Research Institute of Electric Power Industry), Hiroshi Asano (Socio-economic Research Center, Central Research Institute of Electric Power Industry)

キーワード: 太陽光発電，無効電力補償装置，配電系統，費用対効果分析，力率一定制御　　PV，reactive power compensator，distribution network，cost effectiveness analysis，constant power factor control

要約(英語): The installed capacity of photovoltaic (PV) systems has been increasing rapidly due to the enforcement of the feed-in tariff scheme in Japan. However, reverse power flows from the roof-mounted PV systems cause voltage-rises in distribution networks. PV output can be separated into two fluctuation components, short-period and long-period. Long-period fluctuation is compensated by SVR (Step Voltage Regulator) with low response speed, and short-period fluctuation is stabilized by reactive power compensation with high response speed. As for the reactive power compensation, installing SVC (Static Var Compensator) in high-voltage lines has been studied. On the other hand, the idea of installing reactive power compensators in low-voltage lines has been proposed as a promising alternative. This paper proposes a method for analyzing the cost-effectiveness of the reactive power compensators, considering SVR and the constant power factor control of PCS (Power Conditioning System). The proposed method calculates the break-even cost of pole-mounted equipment to SVC, and analyzes the changes in the break-even cost under various power system conditions.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.137 No.1 （2017） 特集：平成28年電力・エネルギー部門大会

本誌掲載ページ: 34-44 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/137/1/137_34/_article/-char/ja/
