単相SCを用いた電圧不平衡抑制装置の導入による配電系統へのPV導入量拡大効果

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2018/02/01

タイトル(英語): Impact on Amount of PV in Distribution System by Suppressing Unbalanced Voltage using Single-phase Static Capacitors

著者名: 猪飼　千真（名古屋工業大学大学院 工学研究科），青木　睦（名古屋工業大学大学院 工学研究科），藤田　悠（（株）トーエネック 技術研究開発部 研究開発G），小林　浩（（株）トーエネック 技術研究開発部 研究開発G），小栗　美香（中部電力（株）電力ネットワークカンパニー 配電部 計画G），山田　琢寛（中部電力（株）電力ネットワークカンパニー 配電部 計画G）

著者名(英語): Yukimasa Ikai (Nagoya Institute of Technology), Mutsumi Aoki (Nagoya Institute of Technology), Yu Fujita (TOENEC CORPORATION), Hiroshi Kobayashi (TOENEC CORPORATION), Mika Oguri (Chubu Electric Power Co., Inc.), Takukan Yamada (Chubu Electric Power Co., I

キーワード: 配電系統，電圧不平衡，進相コンデンサ，SVR，電圧制御　　distribution system，voltage unbalance，static capacitors，SVR，voltage control

要約(英語): In recent years, it is concerned that rapid introduction of residential photovoltaic generation system (PVs) may cause voltage unbalance in high voltage distribution system. Load Ratio control Transformer (LRT) at substation and Step Voltage Regulator (SVR) are used for voltage regulation, however, unbalanced voltage make SVR and LRT difficult to regulate the line voltage. The authors have studied on voltage unbalance suppression system using single phase static capacitors (named SC system), and presented the control method for regulating the line voltage in proper range suppressing the unbalanced voltage. However, the input pattern of SCs is restricted due to the voltage rise caused by PVs. In order to solve this problem, cooperative control in SVR is required to expand the working range of SC system for suppressing voltage unbalance. In this paper, the authors propose the method of determination of a target voltage of SVR for cooperative control with SC system in distribution line connected large amount of PVs. The proposed method is verified by simulation study on distribution system model and the impact on amount of PV is discussed by suppressing unbalanced voltage using SC system.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.138 No.2 （2018） 特集：平成29 年電力・エネルギー部門大会

本誌掲載ページ: 131-139 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/138/2/138_131/_article/-char/ja/
