太陽電池の等価モデルを用いたI-V特性推定型MPPTの提案

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2018/06/01

タイトル(英語): MPPT Method based on I-V Characteristics Estimation by Equivalent Circuit Model of PV Module

著者名: 池野　孝（舞鶴工業高等専門学校），内海　淳志（舞鶴工業高等専門学校），平地　克也（舞鶴工業高等専門学校），中川　重康（舞鶴工業高等専門学校）

著者名(英語): Takashi Ikeno (National Institute of Technology, Maizuru College), Atsushi Utsumi (National Institute of Technology, Maizuru College), Katsuya Hirachi (National Institute of Technology, Maizuru College), Shigeyasu Nakagawa (National Institute of Technolog

キーワード: 太陽電池，MPPT，I-V特性スキャンレス制御，降圧型DC-DCコンバータ，等価回路モデル　　PV modules，MPPT，I-V characteristics scanless control，step-down DC-DC convertor，equivalent circuit models

要約(英語): In order to produce electric power with the highest efficiency from PV modules, it is necessary to operate at a Maximum Power Point (MPP). However, the MPP changes and is affected by external factors such as the of temperature and solar irradiance. In solving the problem, PV modules are in need of Maximum Power Point Tracking (MPPT) such as the perturb and observe method and the I-V characteristics scanning type of MPPT. The latter technique is accurate but it requires a certain time to mesure I-V characteristics and it causes power generation loss. But, the response speed is limited by the measurement system rather algorithm. In this paper, we propose a new MPPT method to solve these problems. This is based on estimating the I-V characteristic by using an equivalent circuit model of PV module. This method is capable of high-speed response and does not equire scanning of I-V characteristics. By experiments, we have demonstrated that the scan-less MPPT at 260ms intervals and that its Useful Utilization Factor (UUF) is 99.9 These performances are equivalent to those of the MPPT method measuring the I-V characteristics directly.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.138 No.6 （2018）

本誌掲載ページ: 514-520 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/138/6/138_514/_article/-char/ja/
