配線用遮断器の直流遮断用アークモデル
配線用遮断器の直流遮断用アークモデル
カテゴリ: 論文誌(論文単位)
グループ名: 【B】電力・エネルギー部門
発行日: 2018/06/01
タイトル(英語): Arc Model to Evaluate D.C. Interruption Performance for Molded Case Circuit Breaker
著者名: 小川 祥央(東京電機大学工学部電気電子工学科),腰塚 正(東京電機大学工学部電気電子工学科),浅草 剛一(三菱重工業(株)),若狭 強志(三菱重工業(株))
著者名(英語): Yoshihisa Ogawa (Tokyo Denki Univ.), Tadashi Koshizuka (Tokyo Denki Univ.), Koichi Asakusa (Mitsubishi Heavy Industries, LTD.), Tsuyoshi Wakasa (Mitsubishi Heavy Industries, LTD.)
キーワード: 配線用遮断器,直流遮断,アークモデル,Cassieモデル,Mayrモデル molded case circuit breaker,D.C. interruption,arc model,Cassie model,Mayr model
要約(英語): Calculations of short line fault (SLF) interruption performance for high voltage gas circuit breakers have been made by using arc models. Cassie and Mayr arc model are well known as an arc model. By combining the one Cassie and two Mayr models, the SLF interruption performance for SF6 gas circuit breaker and CO2 gas circuit breaker is able to be evaluated. Recently, power distribution systems have been changing due to the spread of renewable energy sources. Molded Case Circuit Breaker (MCCB) will interrupt direct current. In this paper, arc model of the air arc was constructed to evaluate the D.C. interruption performance of the MCCB. In the MCCB arc model, the arc parameters which are arc time constant, arc voltage for the Cassie model, arc time constant, arc power loss for the Mayr model were obtained by arc voltage measurements. It is able to set the arc time constants for Cassie and Mayr models are the constant value same as the SF6 gas circuit breaker and CO2 gas circuit breaker. The relation between arc power loss for Mayr model and peak value of interrupting current was derived from measurements. It is shown that the D.C. interruption performance for MCCB can be evaluated by using serially connected three arc models same as SF6 gas circuit breaker and CO2 gas circuit breaker.
本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.138 No.6 (2018)
本誌掲載ページ: 529-534 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/138/6/138_529/_article/-char/ja/
